46 Latest AWS CWI Part B Exam Practice Questions with Answers and Explanations (Metric & Imperial Units)
Are you preparing for the AWS Certified Welding Inspector (CWI) Part B Practical Exam? We’ve created a complete mock test based on the latest official AWS exam guide. These 46 AWS CWI Part B Exam practice questions are designed to help you understand real exam conditions, using plastic replicas, inspection tools, and BoS (Book of Specifications) references.
This mock test includes:
- 46 Questions based on official exam content
- Answer Key after each question
- A brief explanation for every correct answer
- Measurements in both Metric (mm) and Imperial (inch) units
- Covers key topics: visual inspection, weld flaws, BoS interpretation, measuring tools, and WPS compliance.
About the AWS CWI Part B Exam:
The AWS CWI Part B Practical Exam tests your ability to:
- Inspect weld replicas using tools
- Read the AWS Book of Specifications
- Identify discontinuities (defects) like porosity, cracks, undercut
- Use measuring instruments like V-WAC, fillet weld gauge, Bridge-Cam
- Apply WPS/PQR and code-based criteria to real-world welding scenarios
- You’ll be asked 46 questions in 2 hours. A passing score is 72%.
You can take a free practice test for the AWS CWI Part B Exam Quiz course here.
AWS CWI Part B Practice Test (46 Questions with Answers)
Below are all 46 mock questions. Click/tap each to reveal the correct answer and explanation.
Note: This set is useful for anyone preparing for metric or inch versions of the exam.
Download PDF Version:
Prefer to study offline?
Copy and paste in MS Word and export as a PDF
You can take a free practice test quiz course for AWS CWI Part A and Part C:
- Click here to take the free AWS CWI Part A Exam Practice Test
- Click here to take the free AWS CWI Part C Exam Practice Test
Need Help Preparing?
If you need more mock tests or personalized guidance, contact us through the comment section or email us at UpWeld.org@Gmai.Com
If You Want to buy the Latest AWS CWI Exam Self Study Material, Please Feel Free to contact us.
Buy AWS Certified Welding Inspector Exam Learning Package Study Material
IN EVERY 10 QUESTIONS, 1 QUESTION COMES in the exam.
WE HAVE THE LATEST AWS CWI Exam QUESTION BANK
Total 5000+ nos QUESTION BANK FROM THEORY TO PRACTICAL TO NUMERICALS.
Cost: $100
Email Us To Buy: upweld.org@gmail.com
Click Here To Contact On Whatsapp https://wa.link/4dn6ee
Ideally, the only material needed is for passing the examination. Free guidelines during learning.
We give you a lot of additional study material, Free of cost, with this question bank.
Get BOTH Formats Instantly:
Online—Instant scoring, review & reporting.
Printable—Instant download.
AWS CWI Part B – Full Mock Exam (46 Questions)
Below are 46 mock questions formatted with clickable answers. Click/tap each question to reveal the correct answer and explanation.
Q1. Weld Discontinuity – Undercut
A groove weld on a 12 mm (0.5 in) thick plate shows an undercut of 1.2 mm (0.047 in) in length over 40 mm (1.57 in). Is this acceptable?
- A. Yes – Within tolerance
- B. No – Exceeds depth limit
- C. Yes – Length is short enough
- D. No – Exceeds length limit
Explanation: Max undercut depth for thickness > 6 mm is 0.8 mm (BoS Clause 5.6.2).
Q2. Weld Size Inspection – Fillet Throat
A fillet weld is specified to be 6 mm (0.24 in). What is the minimum required throat dimension?
- A. 3.2 mm
- B. 4.2 mm
- C. 4.5 mm
- D. 5.2 mm
Explanation: Throat = 0.707 × leg = 0.707 × 6 = 4.24 mm.
Q3. Visual Inspection – Porosity
You find 4 pores in a 25 mm (1 in) weld segment. The largest is 1.8 mm (0.07 in). The BoS limit for porosity grouping is 3 pores in 25 mm. Is the weld acceptable?
- A. Yes – Diameter is below max
- B. No – Too many pores in 25 mm
- C. No – Any group is rejectable
- D. Yes – Porosity is not cause for rejection
Explanation: More than 3 pores in 25 mm exceeds limits (BoS Clause 5.9.2).
Q4. WPS Compliance – Reinforcement
WPS allows max reinforcement of 2 mm (0.08 in). Actual weld measured at 2.6 mm. What is the action?
- A. Acceptable
- B. Accept if weld is sound
- C. Reject – Exceeds allowed limit
- D. Accept with engineering approval
Explanation: Reinforcement above allowed value per WPS must be rejected.
Q5. Tools – Measuring Weld Reinforcement
Which tool is best suited for measuring reinforcement height?
- A. Fillet gauge
- B. V-WAC gauge
- C. Bridge Cam gauge
- D. Hi-Lo gauge
Explanation: Bridge Cam gauge measures reinforcement, undercut, and angle.
Q6. Gauging Root Opening
Root opening measured is 2.8 mm (0.11 in). If the WPS allows a range of 1.5–2.5 mm (0.06–0.10 in), what’s the result?
- A. Acceptable
- B. Reject – Outside WPS range
- C. Accept with inspection approval
- D. Accept if penetration is good
Explanation: Root opening must comply with WPS limits.
Q7. Book of Specifications – Preheat Temp
According to BoS, what is the minimum preheat for carbon steel plate over 20 mm (0.79 in) thick?
- A. 50°C (122°F)
- B. 100°C (212°F)
- C. 150°C (302°F)
- D. Not required
Explanation: BoS Clause 3.2 specifies preheat based on material thickness.
Q8. Weld Profile – Convexity
Convexity of a fillet weld measures 2.5 mm (0.1 in) on a 6 mm leg weld. BoS allows max convexity = 1/8 of leg size. Is it acceptable?
- A. Yes
- B. No – Exceeds limit
- C. Acceptable if not cracked
- D. Only under engineering override
Explanation: Max convexity for 6 mm weld = 0.75 mm (⅛ × 6).
Q9. Overlap
A groove weld has 0.9 mm (0.035 in) overlap. BoS allows a max of 0.8 mm (0.031 in). What’s the disposition?
- A. Accept
- B. Reject
- C. Rework optional
- D. No effect
Explanation: BoS Clause 5.6.4 – Overlap exceeding 0.8 mm must be rejected.
Q10. Fillet Weld – Actual Size
The specified fillet size is 8 mm (0.31 in). Actual measured leg = 6 mm. What is the disposition?
- A. Acceptable
- B. Reject – Undersized
- C. Accept if length is sufficient
- D. Accept with engineering approval
Explanation: Undersized welds below specified leg dimension must be rejected.
Q11. Weld Gauge Reading
You use a Bridge Cam gauge and measure reinforcement of 3.2 mm (0.126 in). The BoS limit is 2 mm (0.08 in). What’s the result?
- A. Acceptable
- B. Reject – Exceeds reinforcement limit
- C. Accept with note in report
- D. Ignore – not critical
Explanation: BoS restricts reinforcement to 2 mm maximum.
Q12. Crater Crack
A crater crack is found at the end of a weld. What does the BoS require?
- A. Accept if less than 1 mm
- B. Reweld or grind out
- C. Acceptable if not on face
- D. Accept if no spatter
Explanation: Crater cracks are unacceptable and must be repaired.
Q13. Incomplete Fusion
During VT, you notice incomplete fusion on one side of the joint. What is the correct action?
- A. Accept if not deeper than 2 mm
- B. Reject
- C. Accept with UT
- D. Rework if over 50 mm long
Explanation: Incomplete fusion is a critical defect – reject per BoS Clause 5.10.
Q14. Discontinuity – Crack
What is the acceptance criteria for cracks in welds per the BoS?
- A. Allowed if short
- B. Allowed if not open to surface
- C. Not permitted under any circumstance
- D. Only allowed with engineer’s approval
Q15. WPS – Essential Variables
Which of the following is considered an essential variable in a WPS?
- A. Cleaning method
- B. Travel angle
- C. Filler metal classification
- D. Post-weld painting
Q16. Tolerances – Fillet Weld Size
Design calls for a 6 mm (0.24 in) fillet weld. Measured leg size is 4.5 mm (0.18 in). Is this acceptable?
- A. Yes – Within tolerance
- B. No – Undersized weld
- C. Yes – Undersize allowed with approval
- D. Acceptable if intermittent weld
Q17. Weld Profile – Concavity
Concave fillet welds must be evaluated for what primary concern?
- A. Appearance
- B. Undercut depth
- C. Throat thickness
- D. Crack sensitivity
Q18. Interpretation – Weld Symbol
What does a flag on a weld symbol indicate?
- A. Field weld
- B. All-around weld
- C. Backing required
- D. Weld to be inspected
Q19. Code Book – Clause Navigation
Where can you find acceptance criteria for visual inspection in the BoS?
- A. Clause 2
- B. Clause 4
- C. Clause 5
- D. Clause 6
Q20. Defect vs Discontinuity
Which of the following is a correct statement?
- A. All discontinuities are defects
- B. Defects are acceptable if small
- C. All defects are discontinuities
- D. Defects can always be repaired
Q21. Backing – Welding Setup
What is the main purpose of a backing bar in welding?
- A. Provide root reinforcement
- B. Prevent undercut
- C. Maintain heat input
- D. Control weld profile
Q22. Weld Terminology – Face
What is the exposed surface of a completed weld called?
- A. Root
- B. Face
- C. Throat
- D. Toe
Q23. Welding Symbols – Tail Use
What is typically placed in the tail of a welding symbol?
- A. Welding position
- B. Number of passes
- C. Reference to process or spec
- D. Weld size
Q24. Weld Gauge Use
Which tool is typically used to measure fillet weld leg size?
- A. Micrometer
- B. V-WAC gauge
- C. Hi-Lo gauge
- D. Fillet weld gauge
Q25. Code Interpretation – BoS Clause
Which clause in the BoS covers visual inspection?
- A. Clause 2
- B. Clause 4
- C. Clause 5
- D. Clause 7
Q26. Undercut Evaluation
Which of the following undercut depths is unacceptable per BoS for a fillet weld?
- A. 0.4 mm
- B. 0.7 mm
- C. 0.2 mm
- D. 0.5 mm
Q27. Root Opening – Fit-Up
Root opening too large can result in:
- A. Excessive reinforcement
- B. Lack of fusion
- C. Burn-through
- D. Porosity
Q28. Crack Orientation
A transverse crack is oriented:
- A. Along the weld axis
- B. At the root of weld
- C. Perpendicular to weld axis
- D. In the base metal only
Q29. Incomplete Fusion
Incomplete fusion may be caused by:
- A. Excessive travel speed
- B. High amperage
- C. Low arc voltage
- D. Improper joint design
Q30. Weld Joint Types
Which of the following is not a basic weld joint type?
- A. T-joint
- B. Edge joint
- C. Corner joint
- D. Buttress joint
Q31. Maximum Reinforcement
According to BoS, the maximum reinforcement for groove welds is:
- A. 3 mm
- B. 2 mm
- C. 4 mm
- D. 1 mm
Q32. WPS – Position
If a WPS is qualified in 1G position, it may be used in:
- A. All positions
- B. Flat position only
- C. Vertical and overhead
- D. Horizontal only
Q33. Fillet Weld – Effective Throat
What is the effective throat of a 6 mm equal leg fillet weld?
- A. 4.2 mm
- B. 3.0 mm
- C. 6.0 mm
- D. 5.0 mm
Q34. Discontinuity vs Defect
What is the primary difference between a discontinuity and a defect?
- A. All discontinuities are defects
- B. Defects are always acceptable
- C. Discontinuities may or may not be rejectable
- D. Discontinuities require no inspection
Q35. Welding Symbols – Tail
Information such as WPS or process is often found where in a welding symbol?
- A. Arrow
- B. Reference line
- C. Tail
- D. Fillet symbol
Q36. Acceptance Criteria – Porosity
Per BoS, porosity in a groove weld is acceptable if:
- A. It’s less than 2 mm
- B. It doesn’t exceed 5 mm total in 25 mm
- C. It’s completely uniform
- D. It occurs on the root face
Q37. Visual Inspection Equipment
Which of the following is essential for visual weld inspection?
- A. Thermometer
- B. Bridge cam gauge
- C. Taper gauge
- D. Surface comparator
Q38. Back Gouging
What is the purpose of back gouging a weld?
- A. To remove porosity
- B. To improve appearance
- C. To ensure full penetration
- D. To clean the root pass
Q39. Hi-Lo Gauge Use
The Hi-Lo gauge is commonly used to:
- A. Measure weld reinforcement
- B. Check pipe misalignment
- C. Determine leg length
- D. Check porosity
Q40. Overlap Indication
What does overlap typically indicate in a weld?
- A. Poor fusion
- B. Excessive heat input
- C. Improper travel angle
- D. Incorrect base metal
Q41. Welding Positions – 3G
3G refers to which welding position?
- A. Flat groove
- B. Vertical groove
- C. Overhead fillet
- D. Horizontal groove
Q42. Discontinuity Length
According to the BoS, the maximum allowable length for a linear indication in a groove weld is:
- A. 10 mm
- B. 12 mm
- C. 25 mm
- D. 6 mm
Q43. Concavity
What is concavity in a weld profile?
- A. Excess weld buildup
- B. A depression in the weld face
- C. Surface porosity
- D. An overlap indication
Q44. Edge Joint Inspection
In an edge joint, which type of discontinuity is most likely?
- A. Undercut
- B. Lack of fusion
- C. Burn-through
- D. Slag inclusion
Q45. Slag Inclusion Prevention
Slag inclusions can be prevented by:
- A. Increasing arc length
- B. Using more filler metal
- C. Cleaning between passes
- D. Using high voltage
Q46. Weld Size Acceptance
A fillet weld with a leg size of 5 mm is acceptable per BoS if the minimum required is:
- A. 4 mm
- B. 6 mm
- C. 5 mm
- D. 7 mm
